Size: 4.4 x 3.6 x 9.9 Inches (11 x 9 x 25 cm)
Weight: 2.7 lbs (1.2kg) (approx.)
Cortical Bone
Sound velocity / Density / Hardness / T2 / Hounsfield Value / Attenuation at 2.25 MHz
3000 ± 30 m/s / 2.31 g/cm³ / N/A / N/A / 1300 / 6.4 ± 0.3 dB/cm
Trabecular Bone
Sound velocity / Density / Hardness / T2 / Hounsfield Value / Attenuation at 2.25 MHz
2800 ± 50 m/s / 2.03 g/cm³ / N/A / N/A / 1300 / 21 ± 2 dB/cm
Body Tissue
Sound velocity / Density / Hardness / T2 / Hounsfield Value / Attenuation at 2.25 MHz
1410 ± 10 m/s / 1.02 g/cm³ / 60 Shore 00 / 50 ms / 25 / 1.7 ± 0.2 dB/cm
Thermal Properties of Bone-Mimicking Material
Thermal Conductivity / Volumetric Specific Heat Capacity / Thermal Diffusivity / Thermal Resistivity / Specific Heat / Speed of Sound
0.776 W/m·K / 1.040 MJ/m³·K / 0.746 mm²/s / 1.289 m·K/W / 0.978 J/g·°C / 3070 m/s
