AC/DC difference (ppm):
50 Hz: 3
400 Hz: 4
1 kHz: 4
10 kHz: 10
100 kHz: 60
1 MHz: 2500
Phase shift (μrad):
50 Hz: 3
400 Hz: 5
1 kHz: 5
10 kHz: 10
100 kHz: 90
1 MHz: 2500
Input voltage: 7 Vpk
Input impedance: 10 MΩ // 20 pF
- General Specifications:
Power supply: Battery powered, continuous working time after full charge > 7 hours
Temperature performance:
Operating temperature: 13°C ~ 33°C
Storage temperature: 5°C ~ 45°C
Humidity Performance:
Operating humidity: 50% R•H，non-condensing
Storage humidity:（15% ~ 80%）R•H，non-condensing
Weight: Approx. 1.5 kg
I/O connectors:
Input: 50 Ω-N female
Output: 50 Ω-N male
Dimensions: 215 mm (W) ×130 mm (D) ×62 mm (H)
