Physical
Processor: Intel® Icelake-D 4-Core @ 1.9GHz
Memory: 32GB DDR4
Storage: 128GB SSD
ASIC: Broadcom Tomahawk5 BCM78900
BMC: AST2620
Chassis: 2RU, 436W x 762D x 87.7H mm (17.17" x 30" x 3.45")
Weight without FRU: 23.72kg (52.28 lbs)
Redundancy: 1+1 Hot swappable power units
3+1 Hot swappable fan units
Environmental
Power Specs.: AC input: 200 to 240V, 16A
DC input: -40 to -72V, 80A
Typical power: 913 Watts (no transceiver)
Operating Specs.: Operating temperature: 0°C to 40°C (32°F to 104°F)
Operating humidity: 5% to 95% (RH), non-condensing
Non-Operating Specs. : Storage temperature: -40°C to 70°C (-40°F to 158°F)
Storage humidity: 5% to 95% (RH), non-condensing
