Detector Data:
Type: Uncooled FPA
IR resolution: 80×60
Pixel pitch: 17μm
Spectral range: 7.5～14μm
NETD/Sensitivity: <50mK
Lens Data:
FOV: 50°× 37.5°
Image performance:
Display: 3.5” 480×320
Frequency: 9Hz
Focus mode: Fixed
Color palettes: Iron、rainbow and white hot
Measurement:
Temperature range: -20℃～+150℃
Measurement accuracy: ±2℃/±2%
Emission correction: Adjustable from 0 to 0.95, or selected from list of materials
D:S: 15:1
Measurement modes: Spot(center) mode, capture max./min./avg.temperature automatically
Image storage:
Storage capacity: 800
Storage format: JPG
Interface:
Power interface: Yes
Data transmission: USB3.0 Type-C
Power System:
Battery type: Rechargeable Li-ion battery
Operating time: >4h
Charging type: USB
External power DC: 5V
Environmental Parameters:
Operating temperature range: 0℃～+45℃
Storage temperature range: -20℃～+55℃
Encapsulation: IP54
Physical Data:
Size: 125mm×72mm×16mm
Weight: 173g
Others:
Sensor: Direction sensor
Standard packing: Pocket thermal camera, power adapter, USB Type-C cable, user manual, warranty card, certification
