Detector Data:
Type: Uncooled FPA
IR resolution: 640×480
Pixel pitch: 17μm
Spectral range: 7.5～14μm
NETD/Sensitivity: 40mK
Lens:
FOV: 24°×18°
IFOV: 0.68mrad
Focus: Auto/Manual
Lens: Identification Automatic
Lens (optional): 45°×33°,12°×9°
Image Performance:
Display: 4,3” touch screen,LCD with 800×480 pixels
Visual camera: 5.0 mega pixel
Frequency: 50Hz/60Hz
Zoom: 1X～10X continuous
Color palletes: 12 palletes (including iron, rainbow, white hot and black hot etc.)
Contrast/brightness: Auto/Manual
Measurement:
Temperature range: -20℃～+600℃(can be extended to 1200℃)
Temperature accuracy: ±2℃/±2%(reading)
Spotmeter: 10 adjustable spots
Image Storage:
Storage media: 64G SD card, >38400 images
Storage mode: Auto/manual store image in frame
Laser Point: Grade/Type Class 2,1mW/635nmRed
Interfaces:
Power interface: Yes
SD card slot: Yes
WIFI: Yes
Bluetooth: Yes
Video output: HDMI
USB: USB 2.0
Power System:
Battery type: Lithium battery
Battery operation time: 4h continuous
External power DC: 10V～15V
Charging system: Intelligent charger or in camera(AC adapter or 12V car charger)
Power saving: Yes
Environment Parameters:
Operation temp range: -20℃～+50℃
Storage temp range: -40℃～+70℃
Humidity: ≤95%(Non-condense)
Shock: 2G(IEC60068-2-6)
Vibration: 25G(IEC60068-2-29)
Encapsulation: IP54(IEC60529)
Physical Data:
Size: 262mm×125mm×138mm
Weight: ≤950g(with battery and standard lens)
Packing:
Standard: Thermal imaging camera with standard lens, 2 lithium batteries, battery charger, adapter, USB cable, SD card, card reader, software CD, warranty card, calibration certificate
