Working Capacity
Drilling capacity: Ø16 mm
Motor
Motor type: 4-pole squirrel cage rotor
Motor power: 550 W (4P)
Power supply: 220 V, single-phase, 50 Hz
Spindle
Spindle type: MT2 taper (Morse Taper No. 2)
Spindle travel (drill head): 80 mm
Speed
Number of speed levels: 12 steps
Spindle speed: 300 – 2870 rpm
Spindle speed change method: Pulley + Belt
Worktable
Worktable type: Cross table
Worktable size: 420 × 152 mm
Longitudinal travel: 230 mm
Cross travel: 120 mm
Dimensions & Weight
Machine height: 900 mm
Distance from spindle to table: 360 mm
Distance from spindle to column: 182 mm
Net weight: 75 kg
