Table Size (L× W): 480×200mm
Max movement of working table(L× W): 530×220m
T -Slot number×width: 1×14mm
Max distance from spindle center to table surface: 440mm
Wheel Size(Outer diameter×width×Inner diameter): φ200×20×Φ31.75mm
Wheel speed 50HZ: 2850r/min
Wheel speed 60HZ: 3440r/min
Vertical feed on handwheel per revolution: 2.5mm
Vertical feed on handwheel per graduation: 0.02mm
Cross feed on handwheel per revolution: 1.25mm
Cross feed on handwheel per graduation: 0.01mm
Spindle motor: 1.1kW
Coolant pump motor: 40W
The parallelism of working surface to base level: 00:00.0mm
Surface roughness: Ra0.32μm
Net: 700kg
Gross: 800kg
Overall dimension(L×W×H): 1680x1140x1760mm
Package dimension(L×W×H): 1140x1250x1940mm
