Grinding length: 2000mm
Grinding diameter: Φ8~Φ320mm
Center height: 180mm
Max.workpiece weight: 500kg
Worktable speed: 0.1~4m/min
Max.peripheral speed of grinding wheel: 35m/s
Max.travel of table: 2100mm
Swivel range of worktable: 2~+5°
Externalwheef size: Φ600×75×Φ305mm
Workhead spindle speeds: 26,52,90,130,180,260r/min
Grinding spindle speed: 1100r/min
Headstock top: NO.5 morse
Tailstock top: NO.4 morse
Wheelhead displacement per rev of handwheel coarse/fine: 2/0.5mm
Wheelhead displacement per div of handwheel coarse/fine: 0.01/0.0025mm
Machine motor power: 14.27kW
Overall dimensions(L×W×H): 5605×1810×1515mm
Machine weight: 6600kg
