Table size(WxL): 406x813mm
Max.longitudinal travel: 910mm
Cross travel: 450mm
Max.distance from spindle center to table: 580mm
Magnetic chuck size: 400x800mm
Speed of table longitudinal movement: 7-23m/min
Table transerve movement/ Auto feed: 0.1-8mm/min
Table transerve movement/ Repid speed: 990mm/min
Table transerve movement/ Feed of handlwheel: 0.02mm/div.
Wheelhand vertical movement/ Feed of hand-wheel: 0.005mm/div.
Grinding wheel Speed 50HZ: 1450rmp
Grinding wheel Speed 60HZ: 1750rmp
Grinding wheel (ODxWxID) Size: 350x40x127mm
Spindle motor: 4/5.5kw
Hydraulic Motor: 2.2kw
Cooling pump motor: 0.09kw
Elevating motor: -(Hmode)0.25kW(Rmode)0.5kW(D mode servo motor)
Total rated Power: 7.5/9kw
Height of machine: 1890mm
Floor space: 3600x2400mm
Gross weight: 3600kg
Packing dimensions(LxWxH): 2715x265x2250mm
