Main parameters
Temperature range: 15°C to 200°C above room temperature, increment:1℃
Stability: ±0.1°C
Number of sample vials: 27
Preheating positions: 6
Sample vial volume: 10mL or 20mL (Choose one of the two specifications)
Repeatability: RSD ≤ 1.5% (ethanol: water)
Injection pressure range: 0 ~ 0.4MPa (continuously adjustable)
Sample vial
Number: 27
Material: Neutral glass
Volume: 10mL or 20mL (Choose one of the two specifications)
Septum: Butylene rubber coated with teflon (silicon rubber with teflon, optional)
Vial cap: Aluminum
Equilibration area
Preheating positions: 6
Temperature range: 15°C to 200°C above room temperature, increment:1℃
Accuracy: 0.5% of the full range
Stability: ±0.1°C
Sampling system
Temperature range: 15°C to 200°C above room temperature, increment:1℃
Accuracy: 0.5% of the full range
Stability: ±0.1°C
Sampling valve: 6-way valve (MV65/106HT, optional)
Sampling loop: 1mL nickel tube (3mL nickel tube is optional)
Transfer line
Temperature range: 15°C to 200°C above room temperature, increment:1℃
Accuracy: 2.0% of the full range
Stability: ±0.5°C
Needle
Temperature range: 15°C to 200°C above room temperature, increment:1℃
Accuracy: 2.0% of the full range
Stability: ±0.5°C
Electric requirement
Power supply: 220V(±10%), 50Hz, 600VA; (110V±10%, 60Hz, 600VA optional)
Fuses: 5AT, 250V(220V); (10AT,250V(115V) , optional)
