Aalborg P5 Multiple Tube Flow Meter (Five channel)

Standard accuracy: ±2% FS mm scales except 042 and 032 flow tubes. ±5% FS direct reading scales 042 and 032 flow

Calibrated accuracy: ±1% FS

Repeatability: ±0.25%

Useful flow range: 10:1 minimum with one float. Better than 20:1 with combinations of two floats installed in meters

Maximum operating pressure: 200 psig/13.8 bars

Maximum operating temperature: 250 °F/ 121 °C

Number of channel (Number of tube): 5

Details

Datasheet


Manual
