Acore DVTP-50 Vacuum Transformer Oil Purifier (3000l/h,34kw)

Capacity (L/hour): 3000

Vacuum pressure: -0.08～-0.099 Mpa

Working pressure: ≤ 0.4 Mpa

Temperature range: 20-80℃

Continuous work: ≥200 hr

No failure running: ≥5000 hr

Power supply: 380V, 50HZ, 3PH ( or Customized )

Working noise: 65 dB

Heating power (kw): 30

Total power (kw): 34

Inlet/outlet(mm): 32

Weight (kg): 600

Dimension (mm) (L x W x H): 1500×1450×1500 (mm)

Specifications after purification process:

Item Specifications

Breakdown voltage: ≥ 70KV

Water content: ≤ 3ppm

Gas content: ≤ 0.05%

Filtering rate: ≤ 1 micron (ISO 14/12/10)

Flash point (close cup): ≥135℃

Interfacial tension performance: > 40 Dynes / cm @ 25℃

Power factor performance: < 0.005 % @ 25℃
