Additel 918 气动校准泵/ 手动/ 用于压力和空隙

Media: Air.

Generated Pressure Range: 95% vacuum to 1,500 psi (100 bar) positive pressure.

Adjustment Resolution: 0.001 psi (10 Pa , 0.1 mbar).

Material:

Ram/adapters: SS

Body: SS, aluminum

Seals: Buna-N, PTFE, Copper Alloy

Piston volume: 27 ml

Connection

Hand-tight connectors for both test gauge and reference

gauge.

1/4NPT female, 1/2NPT female, 1/4BSP female, 1/2BSP female, or M20X1.5 female

Dimensions:

Height: 5.5" (140 mm)

Base: 12.4" (315 mm) x 7.8" (198 mm)

Weight: 5.7 lb (2.6 kg).

Accessories included

O-ring: 20 pcs

Manual: 1 pc

Carrying case (918-X-SET models only)
