Generated Pressure Range: 95% vacuum to 3,000 psi (200 bar) positive pressure.
Adjustment Resolution: 10 Pa (0.1 mbar/0.0015 psi)
Body: SS, aluminum
Seals: Buna-N, PTFE, Copper Alloy
Piston volume: 60 ml
Hand-tight connectors for both test gauge and reference
1/4NPT female, 1/2NPT female, 1/4BSP female, 1/2BSP female, or M20X1.5 female
Height: 7.00" (178 mm);
Base: 21.26" (540 mm) x 10.63" (270 mm).
Weight: 14.3 lb (6.5 kg).
O-ring: 20 pcs
Manual: 1 pc
Carrying case (920-X-SET models only)
