CS1-F economic type Frequency Indicator has been designed with
high accuracy measurement, display and communication of
The innovation feature is auto-range input from 0.01Hz~
100KHz(option ~140KHz) and the display resolution will
auto-change to show the highest according to input frequency.
They are also available 1 option of 1 Relay outputs, 1 Analogue
output or 1 RS485(Modbus RTU Mode) interface with versatile
functions such as control, alarm, re-transmission or
communication for a wide range of panels and testing applications.
● Measuring Frequency AUTO RANGE 0.01~100KHz / ~140KHz(optional) / Voltage pulse or sine wave(specify).
● Accuracy: ± 0.005%; Display range: 0~99999; Decimal Point auto moving according to input frequency
● Option available 1 of 1 relay, 1 analogue output or RS485(Modbus RTU mode)
● 1 relay can be programmed individual to be a Hi / Lo / Hi Latch / Lo Latch energized with Start Delay /
Hysteresis / Energized & De-energized Delay functions.
● Analogue output or RS 485 communication port in option
● CE Approved & RoHS
