Advanced Energy MDX 1kW DC Power System (1000W)

  • 制造商: Advanced Energy
    Model: MDX 1kW
    保障: 12 month
    • 报价要求 报价要求
  • 联系
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




- Regulation: 0.2%
- Ripple: 5% at 50 kHz
- Ramp Timer: 1 ~ 10 sec or 1 ~ 10 min
- Power Output: 1000W
- Output Voltage: 1000 V, 1300 V
- Ignition Voltage: 1500 V
- Input Power:
115 VAC, 50/60 Hz ±10%, 16 A max
208/220 VAC, 50/60 Hz ±10%, 8.9 A
- Power Factor: 0.6
- Dimension: 175.3 mm (H) x 266.7 mm (W) x 400 mm (D); 6.9" (H) x 10.5" (W) x 15.75" (D)
- Weight: 8.6 kg (19 lb)

- Power Output Connector UHF or terminal block (6-32 screw)
- Ambient Operating Temperature: 0 ~ 40°C (32 ~ 104°F); max value of average over 24 h: 35°C (95°F)
- Coolant Type: Air (gas)
- Coolant Temperature: 0 ~ 35°C (32 ~ 95°F)
- Humidity: 15 ~ 85% relative humidity, no condensing or icing
- Atmospheric Pressure: 800 mbar min (approx. 2000 m above sea level)
