APM SPS200VDC40000W-2-27 直流电源系统 (200V, 240A, 40kW)

Output

Rated Voltage: 200V

Rated Current: 240A

Rated Power: 40kW

Size: 27U / 600.0x1196.0x700.0mm & 120kg+15kg*10(REF)

Voltage: 190~265VAC

Frequency: 47~63Hz

Phase: 3 Phase, 4Wire+Groud/Y Connect

Max.Current: 250A

Input Power Max: 47.5kW

Power Factorat 220VAC Input, Full Load: 0.98 Min. Active PFC

Efficiency: >88% Max at Full Load and Units=4kW Model

Interface: USB, RS485, RS232(Standard); LAN, GPIB(Option)

Catalogue / Datasheet
