APM SPS225VDC12000W-2-13 直流电源系统 (225V, 60A, 12kW)

Output

Rated Voltage: 225V

Rated Current: 60A

Rated Power: 12kW

Size: 13U / 600.0x576.0x700.0mm & 53.5kg+15kg*3(REF)

Voltage: 190~265VAC

Frequency: 47~63Hz

Phase: 3 Phase, 4Wire+Groud/Y Connect

Max.Current: 75A

Input Power Max: 15kW

Power Factorat 220VAC Input, Full Load: 0.98 Min. Active PFC

Efficiency: >88% Max at Full Load and Units=4kW Model

Interface: USB, RS485, RS232(Standard); LAN, GPIB(Option)

Catalogue / Datasheet
