Artesyn AEE03C36-L 50 Watt Isolated DC-DC Converter (15V; 3.33A; 50W)

Input range: 18 - 75 Vdc

Efficiency: 92% @ 12 Vo

Output Voltage: 15 V @ 3.33 A

Maximum Power: 50 W

Voltage tolerance: ±1.0%

Line regulation: ±0.5%

Load regulation: Single output: ±0.5%

Noise/ripple: 3.3 Vo, 5 Vo: 100 mV; Others: 150 mV

I/O isolation: 1500 Vdc min.

Operating ambient temperature range: -40 °C to +85 °C

Storage temperature: -50 °C to +125 °C

Humidity: 5% to 95% (non-condensing)
