Artesyn AXA00AA18-L 1x1 inch Low Power Isolated DC-DC Converter (±5V; ±1A; 10W)

Input range: 9 - 36 Vdc

Efficiency: 84%

Output voltage: ±5 V

Output Current: ±1 A

Max Output Capacitance: 220 µF

Power: 10 W

Voltage tolerance: ±2.0%

Line regulation: ±0.3%

Load regulation: ±0.5%

Noise/ripple: 100 mV

I/O isolation: I/O: 1500 Vdc

Operating ambient temperature range: -40 °C to +80 °C

Storage temperature: -50 °C to +125 °C

Humidity: 5% to 95% non-condensing


Detail

Datasheet
