Artesyn DS750PED-3 Front-end Power Supply (12V/62.5A; 12VSB/3A; 750W)

Input

Input range: 90 - 264 Vac

Frequency: 47 Hz to 63 Hz

Efficiency: 94.0% peak

Max Input current: 10.0 Arms @ 90 Vac

Output

Main DC Output:

Nominal setting: MIN: -0.20%/ NOM: 12/ MAX: 0.20%

Total output regulation range： MIN: 11.4 V/ MAX: 12.6 V

Output current: MIN: 0.5 A/ MAX: 62.5 A

Standby DC Output:

Nominal setting: MIN: -1%/ NOM: 12/ MAX: 1%

Total output regulation range: MIN: 11.4 V/ MAX: 12.6 V

Output current: MIN: 0.1 A/ MAX: 3.0 A

Protection: OVP, OCP, Short Circuit, OTP

Operating temperature: 0 to 50 °C, withstand operation up to 60 °C at full power without damage

Operating relative humidity: 20% to 80% non-condensing

Non-operating temperature: -40 to +70 °C

Non-operating relative humidity: 10% to 95% non-condensing

Nominal Main Output: 12 V @ 62.5 A

Standby Output: 12 V @ 3 A

Airflow Direction: Standard (forward)
