Warranty: 12 months
- 2 microplates, 80 sample rack, 92 dilution rack.
- 8 special reagent racks, 1 general reagent racks.
- Biological safety protection provides the high level of operator and environmental protection.
Sample Pipetting Unit
Sample Rack:80 sample positions(tubes 12mm)
Primary Sample Tubes:12*75mm
Pipetting: 10ul~1000ul, (100ul) CV<0.5%
Dispensing System: 1 aspirating-dispensing probe with X-Y-Z movement; dilution system with a syringe of 1000ul, continuous flow washing station.
Reagent Pipetting Unit
Reagent Racks: 8 special reagent racks,1 general reagent racks
Removable Trays: Modular racks to hold calibrators, controls and reagents for 8 test on line
Pipetting: 10ul~1000ul,1ul stepping
Pipetting precision: (100ul) CV<0.5%
Time to Dispense: 4 minutes adding 96 reagents
Incubators: 2 independent units
Temperature Range: RT to 45 °C
Temperature Accuracy: ±0.5°C
Temperature Fluctuation: ±0.5°C
Programmable: Yes(options & parameters)
Wash Containers: 2 wash buffers at 2.0L, with level-sensing
Washing System: Two 8 nozzle manifolds, one to dispense and the other one to aspirate
Washing Residual: <2μl
Reading System: 8 independent photometric channels with mono and dichromatic reading capability
Photometric Range: 0.000 ~3.000 OD
Spectral Range: 400-700nm
Optical Filters: 2 precision filters (450,630nm); 2 more on request (4 filters max, 400-700nm)
Software System: Windows 7/8/10 or above, LIS system available
Function Application: Work list set up, patient reports and result filing; calibration curve storage for each carried out test
Data Reduction: cut-off (qualitative)
Package Size(W*D*H): 1020*810*1240mm
Gross Weight: 160kg
Power Supply: AC220V+10%,50/60Hz;110V+10%,60Hz; 500W
