BK Precision 1900B 旋钮式交换式直流电源(16V,60A,960W)

Variable Output Voltage 1 – 16 V
Variable Output Current 0 – 60 A
Maximum Output Power 960 W
Load (0-100% Load) ≤ 50 mV
Line (90-132 VAC, 170-264 VAC Variation) ≤ 20 mV
Load (10-90% Rated Voltage) ≤ 200 mA
Ripple & Noise Voltage (rms) ≤ 5 mV
Ripple & Noise Voltage (peak-peak) ≤ 50 mV
Transient Response Time (50-100% Load) 1.5 ms
Power Factor Correction > 0.95 at optimal load
Cooling Method Thermostatically controlled fan from zero to full speed
Protections Overload, Short Circuit by Constant Current, Overvoltage, Overtemperature
Special Features 3 User-Defined Voltage and Current Presets, Analog Remote Control, Remote Sense (model 1900B only)
Operating Temperature 32 °F to 104 °F (0 °C to 40 °C), ≤80% R.H.
Storage Temperature 5 ºF to 158 ºF (-15 ºC to 70 ºC), ≤85% R.H.
Dimensions (W x H x D) 7.9” x 3.5” x 10.8” (200 x 90 x 275 mm)
Weight 7 lbs (3.2 kg)
