BK 9803 可编程AC交流电源供应器(750VA,6A,300V)

  • 制造商: BKPRECISION
    Model: 9803
    来源: China
    • 报价要求 报价要求
  • Price (exclude tax) 77,080,000 VND
    Price (include tax) 84,788,000 VND
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




-AC Input
Phase Single
Voltage 110 / 220 VAC ± 10%
Frequency 47 - 63 Hz
Max. Current 15A max.
Power Factor 0.7 (typical)
-AC Output
Max. Power 750 VA
Max. Current (rms)
0 - 150 V: 6 A
0 - 300 V: 3 A
Max. Current (peak)
0 - 150 V: 24 A
0 - 300 V: 12A
-Programming
Voltage (rms)
Range 0 -300 V, 150 V / 300 V (Auto)
Resolution 0.1 V
Accuracy ±(0.2% + 0.6 V)
Frequency
Range 45 - 500 Hz
Resolution 0.1 Hz at 45 - 99.9 Hz
1 Hz at 100 - 500 Hz
Accuracy ±0.1 Hz (100 Hz)
±1 Hz (100 - 500 Hz)
Phase Angle
Range 0 - 360°
Resolution 0.1°
Accuracy ±1° (45 - 65 Hz)
-Measurements
Voltage (rms)
Range 0 - 300 V
Resolution 0.1 V
Accuracy ±(0.2% + 0.6 V)
Current (peak)
Range 0 - 24 A
Resolution 0.01 A
Accuracy ±(1% + 120 mA)
-Memory 10 Locations
-External BNC I/O Trigger input, sync output, output status,
output indicator / control
-Interface LAN, USB, RS232, GPIB
-Standard Accessories
AC Power cord (9801 only), unterminated power cord with
input connector (9803 & 9805 only), rackmount ears &
handles (9803 & 9805 only), instruction manual,
test report & certificate of calibration
-Optional Accessories IT-E151 rack mount kit (9801 only)

Details

Download datasheet
