BKPRECISION RFP3018 射频功率传感器,实时 (18 GHz)

RF Frequency Range: 50 MHz to 18 GHz

Video Bandwidth (high/std): 70 MHz / 350 kHz

Dynamic Range

Average: -34 to +20 dBm

Pulse: -24 to +20 dBm

Power: Consumption 2.5 W max (USB High-Power device)

Rise Time (fast/std): 4 ns / < 10 μs

Video Bandwidth (high/std): 165 MHz / 350 kHz

Single-shot Bandwidth: 35 MHz

RF Input Type: Type N, 50 Ω

VSWR: 1.20 (0.05 to 6 GHz); 1.25 (6 GHz to 8 GHz)

Dimensions: (H x W x D) 1.7” x 1.7” x 5.7” (4.3 cm x 4.3 cm x 14.5 cm)

Weight: 0.8 lbs (0.36 kg)

Warranty 3 years

Standard Accessories: 0.9 m BNC (m) to SMB (m) cable, 0.9 m SMB (m) to SMB (m) cable, 1.8 m USB A (m) to USB B (m) locking SeaLATCH cable, power cord, test report & certificate of calibration
