BUCK L-4 个人气体采样泵 (5-4000 cc/min)
制造商: BUCK Model: L-4 来源: USA 保障: 12 Month - 联系
Specification:
- Flow Range: 5-4000 cc/min, 5-800cc/min With Universal Low Flow Holder P.N. APB-109030
- Compensation Range:
1.5 LPM up to 15” water backpressure
2.0 LPM up to 35” water backpressure
2.5 LPM up to 30” of water backpressure
3.0 LPM up to 20” water backpressure
4.0 LPM up to 8” water backpressure
- Accuracy: ± 5% of Compensation Range
- Run Time (hrs) at different backpressure and flow rate
Flow Rate cc/min
Filter 2000 2500 3000 4000
37mm 0.8µ PVC 23Hr 19Hr 18Hr 16Hr
37mm 0.8µ MCE 21Hr 16Hr 16Hr 13Hr
25mm 0.8µ MCE 15Hr 12Hr 10Hr
25mm 0.45µ MCE 11Hr 10Hr
- Data Storage: Flow rate, elapsed clock time, accumulated volume, temperature, DP and any Flow Faults are logged in the memory for download to PC
- Display: Backlit LCD with 2 lines of 16 Characters
- Normal Operation: Battery Level, Flow Rate, Elapsed Time, Volume Collected, Timer, DP & Temp.
- Flow Fault Displays: Flow Fault, or Filter Off
- Power Supply: Single Pack, NiMH Batteries: 4.8V, 2.15 Ah
- Recharge Time:Standard 16 Hrs (Optional QuickOne™ 1 Hrs)
- Standard-Chargers: Input Voltage 230 VAC (APB– 926020)
- Approvals: CE EMC Directive (EMCD) 89/336/EEC UL and cUL (pending), ATEX (pending)
- Temperature
Operating 32°F to 113°F (0°C to 45°C)
Storage 32°F to 113°F (0°C to 45°C)
Charging 41°F to 104°F (5°C to 40°C)
- Case: Polycarbonate steel fiber filled, RFI/EMI-shielded
- Size: 11.4 cm H x 10.2 cm W x 5 cm D
- Weight: 453g
Pump kit includes
- pump
- Single pack NiMH battery
- Standard 230VAC battery charger
- Luer hose adapter
- Shirt/hose clip
- 3 feet of vinyl hose
- Operating manual
