California Instruments 751i 精密可编程交流电源(750W,300V,40A)
制造商: Ametek Model: 751i 保障: 12 Month - 报价要求
- 联系
Voltage: 115Vrms +/- 10% or 230Vrms +/- 10%
Current:
<8.5 Arms @ 115 V
<4.4 Arms @ 230 V
Frequency: 47 to 63 Hz
Power Factor: 0.97 (typical @ full load)
Efficiency: 80%
AC output
Voltage : Hi : 0 - 300Vrms; Low : 0 - 150Vrms
Max. Current: Hi : 3.25 Arms; Low : 6.5 Arms
Peak Current Hi : 10 A Peak ; Low : 20 A Peak
AC Power: 750VA
Phase Output: 1
Distortion: < 1% THD
DC Output
Voltage : Hi : 0 - 400Vdc; Low : 0 - 200Vdc
Max. Current : Hi : 1.63 Adc ; Low : 3.25 Adc
DC Power: 500W
Voltage Accuracy/Programming Resolution (AC/DC)
Accuracy (ALC mode ON): 0.1% FS (from 5V to FS)
Programming Resolution: 0.1V
Frequency
Range: 16 – 1000Hz
Resolution:
0.01 Hz (16 – 81.91 Hz)
0.1 Hz (82.0 – 819.1 Hz)
1 Hz (820– 1000 Hz)
Accuracy: 0.025%
Interfaces
USB: Standard
GPIB: Option
Please check the datasheet for details
