Voltage DC: 400mV, 4V, 40V, 400V, 1000V ±(0.5%+2d)
Voltage AC: 400mV, 4V, 40V, 400V, 750V ±(0.8%+4d)
Current DC: 400uA, 4000uA, 40mA, 400mA, 4A, 20A ±(1.2%+2d)
Current AC: 400uA, 4000uA, 40mA, 400mA, 4A, 20A ±(1.5%+4d)
Resistance: 400Ω, 4kΩ, 40kΩ, 400kΩ, 4MΩ, 40MΩ ±(0.8%+3d)
RPM(Tach): 600 ~ 4000RPM; 600 ~ 12000RPM(x 10RPM) ±(2.5%+2d)
Dwell Angle: 1CYL, 2CYL, 3CYL, 4CYL, 5CYL, 6CYL, 8CYL, 10CYL, 12CYL ±(2.5%+2d)
Duty Cycle: 0.1~99.9% ±(1.5%+5d) ±(1.5%+5d)
Period: 0.1~20mS ±(3.0%+5d)
Pulse Width: 0.1~10mS ±(3.0%+5d)
Frequency: 30kHz ±(2.0%+2d)
Temperature: -20ºC ~ 760ºC/-4ºF ~ 1400ºF ±(3.0%+2d)
Diode Check: Open circuit voltage 3V dc; Test current 0.3mA typical.
Continuity Test: Threshold 30Ω, Continuity Beeper 2.7kHz
Interface: Wireless USB
Size(HxWxD): 197mm x 88.4mm x 41.2mm
Weight: 635g
Accessories :
Rubber holster, Test leads, type K temperature Probe, software, RS-232 cable/USB interface, Pick-up, 9V battery and gift box with carrying case.
