CEM DT-178B 3轴 振动测试仪

Acceleration Sensor: MEMS Semiconductor

Acceleration Sensor sampling Rate: 256Hz

Acceleration Range: ±18g

Acceleration Resolution: 0.00625g

Acceleration Accuracy: ±0.5g

Non-Linearity: ±1%

Bandwidth: Approx.0-60Hz

Trigger Range: 0 to 18g(XYZ magnitude)

Temp & Humidity Range:-40 to 70℃/-40 to 158℉; 0 to 100%RH

Temp & Humidity Resolution: 0.1%RH/0.1℃/℉

Temp & Humidity Accuracy: 2%RH/1℃/℉

Sampling Rate: 1sec. to 24hours

Memory: 8Mbit FLASH

(Memory for 504126 samples, about 168042samples/.axis for x, y and z axis separately)

Accessories: 3.6V Lithium battery, software and clamshell.
