CEM DT-3352 AC/DC钳形表 (AC/DC-1500A, AC-1000V, DC-750V True RMS)

Function: Max. Range - Basic Accuracy

Current DC: 1500A  ;  ±(2.0%+10d)

Current AC: 1500A  ;  ±(2.8%+10d)

AC kW/kVA

900.0kW  ;  ±(3.0%+10d)

( AC kW/kVA TRMS 0-600V, 0-1500A, 50/60Hz)

DC kW/kVA

900.0kW  ;  ±(2.5%+10d)

( DC kW/kVA 0-600V, 0-1500A, 50/60Hz)

Power Factor: 0.3~1  ;  ±(2.5%+10d)

Voltage DC: 1000.0V  ;  ±(0.1%+5d)

Voltage AC: 750.0V  ;  ±(0.5%+5d)

Resistance: 40.000MΩ  ;  ±(0.5%+4d)

Temperature: 1000ºC/ 1832ºF  ;  ±(1.0%+1ºC/1ºF)

Capacitance: 40.00mF  ;  ±(2.5%+5d)

Duty Cycle: 10.0 to 95.0%  ;  ±(0.5%+2d)

Frequency: 40.000MHz  ;  ±(1.2%+2d)

Inrush Current: 1500A  ;  ±(1.5%+2d)

Continuity check: Buzzer sounds at 50Ω

Diode test: Test current 0.3mA

Size (H x W x D): 295mm x 100mm x 46mm

Weight: 537g


Accessories: Test leads, gift box with carrying case and 9V battery Temperature probe.


Details

Datasheet


Features

DT-3351

DT-3352

Current measurement

AC/DC

AC/DC

Power clamp meter

*

LCD display counts

40000

40000

AC True RMS

*

*

Display with backlight

*

*

Inrush current measurement

*

*

Max /Min, Data Hold

*

*

REL (Zero) Function

*

*

Auto Power Off

*

*

Low battery indication

*

*

Analog Bargraph / 41 seg.

*

*

2.16” (55mm) Jaw opening

*

*

NCV Detection

*

*
