CEM DT-9232 Electrical Testers (LED 12V~1000V AC/DC, LCD 6V~1000V AC/DC)

LEDs

Voltage range: 12 V to 1000 V ac/dc

Resolution: ±12V,24V,50V,120V,230V,400V,690V,1000V

Frequency range: 0/40Hz to 400 Hz

Response time: ≤0.5 seconds

Auto power on: ≥12V ac/dc

LCD

Voltage range: 6V to 1000V ac/dc

Resolution: ±1V

Tolerance: ±(3%rdg + 5digits)

Frequency range: 0/40Hz to 400 Hz

Response time: ≤1 seconds

Auto power on: ≥6V ac/dc

Voltage detection: Automatic

Polarity detection: Full range

Range detection: Automatic

Internal basic load impedance Peak current: Maximum 3.5mA at 1000 V 200 kΩ/1s<3.5mA(no RCD tripping)

Operation time: Duration Time = 30 seconds

Recovery time: Recovery Time =240 seconds

Switchable Load: ﹣7 kΩ

Peak current: Is(load) = 150mA

RCD triping: I = 30mA at 230V

Continuity Test: 0 to 400kΩ

Accuracy: nominal resistance ﹢50%

Test current: ≤5 μ A

Single-pole Phase Test: 100V ac to 1000V ac

Frequency range: 50Hz to 400Hz

Rotary Field Indication

Voltage range(LEDs): 100V to 1000V(phase to earth)

Frequency range: 50 Hz to 60Hz

Resistance Measurement: 0Ω to 1999Ω

Resolution: 1Ω

Tolerance: ±(5%rdg + 10 digits) at 20℃

Temperature coefficient: ±5 digits/10K

Test current: ≤30μA

Size (HxWxD): 240mm x 78mm x 30mm

Weight: 237g


Accessories:

Two “AAA” batteries, gift box with carrying case.

Detail

Datasheet


Features

9230

9231

9232

9233

Complies with EN 61243-3:2014

*

*

*

LED Indication Range: 12 V to 600 V dc and ac

*

*

LED Indication Range: 12 V to 1000 V dc and ac

*

*

*

Independent ELV indicator LED, indicates if >50 V ac/120 V dc is present even in the event of no battery power or main circuit failure

*

*

*

*

LCD Indication Range: 6 V to 1000 V dc and ac

*

*

Resistance Measurement: LCD 3½ digit (0 to 1999 Ω/1Ω resolution)

*

*

LCD Backlight Display HOLD: Freeze/unfreeze display with voltage or resistance measurement

*

*

Fixed Impedance ~200 kΩ (≤3.5 mA @ 1000 V)

*

*

*

Switchable Load by 2 pushbuttons (30 mA @ 230 V)

*

*

*

Vibration During Load (when 2 switchable load pushbuttons are pushed)

*

*

*

Single-Pole Phase Test (also operates with gloves)

*

*

*

Rotary Field Direction (also operates with gloves)

*

*

*

Continuity Test / Diode Test

*

*

*

Fashlight

*

*

*

Beeper for Continuity/Phase/ACV

*

*

*

*

19 mm Probe Tip distance when docked

*

*

*

*

CAT III 1000 V / CAT IV 600 V

*

*

*

*

IP64

*

*

*
