CEM DT-9986 绝缘测试器,具有RMS万用表 (True RMS, AC/DC-1000V, 4000MΩ)
制造商: CEM Model: DT-9986 来源: China 保障: 12 Month - 报价要求
- 联系
Multimeter
Function: Max Range - Resolution - Basic Accuracy
DC Voltage: 1000V ; 0.1V ; ±(0.06% reading + 4digits)
AC Voltage: 1000V ; 0.1V ; ±(1.0% reading + 30 digits)
DC Current: 10A ; 0.001A ; ±(1.0% reading + 3 digits)
AC Current: 10A ; 0.001A ; ±(1.5% reading + 30digits)
Resistance: 40MΩ ; 0.0001MΩ ; ±(0.3% reading + 4 digits)
Frequency: 40MHz ; 0.01MHz ; ±(0.1% reading + 1 digits)
Duty Cycle: 0.1 to 99.90% ; 0.01% ; ±(1.2% reading + 2 digits)
Temperature: -50 to 1200°C/ -58 to 2192°F ; 0.1°C / 0.1°F ; ±(1.0% reading + 2.5°C/4.5°F)
4-20mA%: -25 to 125% ; 0.01% ; ±50 digits
Insulation
Terminal Voltage: 125V (0% ~10%)
Range - Resolution - Accuracy
0.125~4.000MΩ ; 0.001MΩ ; ±(2%+10)
4.001~40.00MΩ ; 0.01MΩ ; ±(2%+10)
40.01~400.0MΩ ; 0.1MΩ ; ±(4%+5)
400.1~4000MΩ ; 1MΩ ; ±(5%+5)
Test Current: 1mA at load125kΩ
Short circuit current: ≤1mA
Terminal Voltage: 250V (0% ~10%)
Range - Resolution - Accuracy
0.250~4.000MΩ ; 0.001MΩ ; ±(2%+10)
4.001~40.00MΩ ; 0.01MΩ ; ±(2%+10)
40.01~400.0MΩ ; 0.1MΩ ; ±(3%+5)
400.1~4000MΩ ; 1MΩ ; ±(4%+5)
Test Current: 1mA at load250kΩ
Short circuit current: ≤1mA
Terminal Voltage: 500V (0% ~10%)
Range - Resolution - Accuracy
0.500~4.000MΩ ; 0.001MΩ ; ±(2%+10)
4.001~40.00MΩ ; 0.01MΩ ; ±(2%+10)
40.01~400.0MΩ ; 0.1MΩ ; ±(2%+5)
400.1~4000MΩ ; 1MΩ ; ±(4%+5)
Test Current: 1mA at load1500kΩ
Short circuit current: ≤1mA
Terminal Voltage: 1000V (0% ~0%)
Range - Resolution - Accuracy
1.000~4.000MΩ ; 0.001MΩ ; ±(3%+10)
4.001~40.00MΩ ; 0.01MΩ ; ±(2%+10)
40.01~400.0MΩ ; 0.1MΩ ; ±(2%+5)
400.1~4000MΩ ; 1MΩ ; ±(4%+5)
Test Current: 1mA at load1MΩ
Short circuit current: ≤1mA
Size(HxWxD): 220mm x 96.5mm x 60.5mm
Weight: 631g
Accessories
Test leads, 6x1.5V“AAA” batteries, Type K temperature probe, USB cable and Software(9985RF/9986), gift box with carrying case.
Datasheet
Features | DT-9985 | DT-9985RF | DT-9986 |
Save both time and money with Automatic calculation of Polarization Index and Dielectric Absorption Ratio | * | ||
200 mA Continuity | * | ||
Compare function (pass/fail) for fast repeated tests | * | ||
Insulation test voltages 125V, 250V, 500V, 1000V | * | * | * |
Insulation test: 0.001MΩ to 4000MΩ | * | * | * |
Auto discharge of capacitive voltage | * | * | * |
Insulation test smoothing reading | * | * | * |
Min/Max function | * | * | * |
K-type thermocouple | * | * | * |
Rugged, utility hard case | * | * | * |
Auto power off to save battery power | * | * | * |
True-RMS | * | * | * |
Large LCD display with backlight | * | * | * |
CAT III 1000V, CAT IV 600V measurement category | * | * | * |
IP67 Waterproof and Auto Power Off | * | * | * |
Wireless USB interface | * | * |
