Chauvin Arnoux PAC 16 钳表 (600A)

- Input

+ Current: 0.5 to 40 A AC; 0.5 to 60 A DC; 0.5 to 400 A AC; 0.5 to 600 A DC

+ AC: yes

+ DC : yes

- Output / Connections

+ Voltage: 600 mV; AC/DC

+ Leads + safety plug ø 4 mm: yes

- Specific features

+ Transformation ratio (input/output): 1A/10mV; 1A/1mV

+ Automatic zero DC: yes

+ Bandwidth (frequency in Hz): DC- 30 kHz

+ Typical accuracy: ≤ 1.5 %; ≤ 2%
