Stroke: 1100mm(without grips)
Force precision: 1/20,000
Stroke resolution: 0.0001 mm
Test speed: 0.1~300mm/min
Speed precision: 0.1 ~ 3 mm/min ± 2% ; 3 ~ 300 mm/min ± 1%
Distance between two columns: 550mm
PC Port: USB
Hardware protection: up/down limit, emergency stop button.
Mechanism configuration: Adopting Servo-motor driven, precise decelerators and ball screws to reduce the noisy, loss of transmission.
Force sensor: Load Cell comply with ASTM-E4 standard which accuracy is limited within 1.0 %
Power: 3 phase,200~240VAC, 30A
Dimension: 140 x 70 x 235 cm
Weight: 1250 kg
