Temperature: Room temperature up to 300℃
Temperature Control: 50℃ increase per minute (adjustable)
Weight: Method A: 1 Kg, Method B: 5 Kg
Deflection Reading: 0.001~3.000 mm
At least two flat, smooth, parallel specimens with thickness 3 to 6.5mm and area 10 x 10 mm or Ø10mm mm2 are needed.
If the specimen is thicker than 6mm, reduce it by half on one side and keep the other side unchanged.
If the thickness is below 2.5 mm, stack the specimen with less than 3 other materials and make the combination at least 3 mm thick.
1. 7” colored touch screen that shows multiple test data
2. Load data is completely recorded and data exportable to Excel.
3. User-friendly operation and illustration-guided interface
4. Jigs are replaceable
Cooling Method: Water cooling
Stations: 1, 2, 3 (choose)
Power: Single phase, AC 220V
Tester Dimension: 85 X 48 X 54 cm
