Comet P8653 带PoE的Web传感器-两个通道，带洪水检测器和二进制输入 (PoE/ 5Vdc, Ethernet)

Measured value: Temperature, Relative humidity, Two-state signal

Temperature sensor:

  Measuring range: -55 to +105 °C

  Accuracy: according to the connected probe DSxx

  Resolution: 0.1 °C

Humidity sensor:

  Measuring range: according to the connected probe DSxx

  Accuracy: according to the connected probe DSxx

  Resolution: 0.1% RH

Flood detector:

  Usage Intended: for indoor usage only

  Cable length: 2.5 meters (can`t be extended)

  Two wire connection: red wire – active, black wire – GND, directly powered from P8653

Binary input:

  Parameters of the voltage contact Voltage input level for „L“:< 1,0 V;

         Voltage input level for „H“: > 2,5 V;

             Internal resistivity of the voltage source: < 2kOhm

        Input voltage range: 0 to +30 V

  Parameters of the voltage-free contact: Voltage on the unclosed contact: 3,3 V

      Current through closed contact: 0,1 mA

        Maximum resistivity of the contact: < 5kOhm

Operating temperature: -20 to +60 °C

Channels: 1x external temperature probe nebo 1x connectable temperature+humidity probe

Output: Ethernet

Measuring interval: 2 s

Available temperature units: degrees Celsius, degrees Fahrenheit

Communication protocol: WWW, ModbusTCP, SNMPv1, SOAP, XML

Alarm protocols: E-mail, SNMP Trap, Syslog

Power: Power over Ethernet according to IEEE 802.3af or 5Vdc

Protection class: IP30

Dimensions: 88 x 74 x 39,5 mm

Weight: approx. 125 g

Included in delivery:

  P8653

  Instruction Manual

  Traceable Calibration Certificate

  FREE software TSensor for Configuring of the Transmitter

  COMET Cloud for 3 Months

  Flood detector LD-81

  EXTERNAL PROBES ARE NOT INCLUDED IN DELIVERY
