DaiHan WEV-0095 真空泵 (57L,0.098MPa)

Max. Vacuum Degree: 0.098 MPa (20mbar)

Pump Power(Capacity): 550 W

Water Bath Volume(Lit): 57 Lit

Useful for Evaporator Capacity: for 5~50 Lit

Flow Rate: 100 Lit/min

Taps & Air Sucking Amount: 5 Taps, 10 Lit/min (1 Tap)

External Circulation Nozzle: id. 8/ od. 11mm Silicon tube Connected for Circulation

Safety Function: Safety Check Valve

Drain Pipe: Drain Pipe(id. 24.3 mm)

Material of Water Tank/Body: Stainless-steel (#304)

Dimension & Net Weight: 450 x 350 x h820 mm/36 kg

Electric Reqts.: 230V, 50/60Hz
