DaiHan MS-20A 类比/电子式控制 电磁式搅拌器 (1,500rpm, 20L)

Plate Size: 180 x 180 mm

Stirring Capacity: Max.20Lit(H2O)

Speed Range: Max 1,500rpm

Motor Rating (Input/Output): 9/4W

Controller: Superior Linearity PWM Controller

Stirring Bar: 3cm bar-included, Usable: up to 5 cm bar

Permissible Ambient Temp.: Room Temp. +5~50°C

Permissible Relative Moiture: 85%

Material:

+ Plate: Ceramic Coated Aluminum (Chemical/Acid Resistance)

+ Body: Powder Coated Aluminum

Dimension (w x d x h): 206 x 307 x 99 mm

Weight: 3.1 kg

Packing Size (w x d x h): 280 x 400 x 200 mm

Gross Weight: 5kg

Power Consumption: 10W

Electrical Reqts. : Free Voltage ( 1 Phase, AC 80~240V 50/60 Hz)
