DaiHan HG-15D 数显分体式分散机 (27,000rpm, 2,500ml)

Speed Range & Resolution: 2,000~27,000 rpm (without load) 10 rpm-Control

Working Range: 1 ~ 2,500ml

Motor Rating (Input/ Output) Input : 300W, Output : 160 W

Timer & Alarm: 10 sec ~ 15 min, Timer-end Alarm

Display: Digital LCD wwith Back-Light Function

Controller: Digital Feedbak Controller (Remote Type)

Safety Device: Over Heat Protector

Usable Dispersing Tool: Φ8mm Stator "HT1008", Φ10mm Stator "HT1010", Φ18mm Stator "HT1018", Φ25mm Stator "HT1025"

Material: Aluminum Die-casting and ABS-Unit, Stainless-steel (# 304)-Tool

Permissible Temp. & Moisture Ambient +5~50°C, 85%

Extension Arm Size: Φ12.7 x L250mm

Dimension & Weight: 60 x75 x h215mm, 2.5kg

Power Consumption: 160W

Electrical Reqts.: AC 230V, 50 / 60Hz
