Temp.Range & Variation: 10°C~60°C, ±1°C at 20°C
Temp. Fluctuation: ±0.5°C at 10°C, ±0.5°C at 25°C(0% light intensity); ±1°C at 10°C, ±1°C at 25°C(100% light intensity)
Humidity Range & Variation: 30%~95% RH, ±3% at 60°C
Humidity Fluctuation: ±1%
Humidifier: Evaporation by Fan with Heater
Illumination Range: 0 to 15000 lux
Illumination Lamp: FPL 55W x 28
Illumination Bank: 3 Side Walls
Temp.& HUmidity Sensor: Temp.:PT100, Humidity: Capacittive Sensor
Heat-up Time(up to 37°C): 11 min. (0% Illumination)/9 min. (100% illumination)
Cool-down Time(down to 10°C): 13 min. (0% Illumination)/15 min. (100% illumination)
Temp. Recovery(After Door was opended for 30 sec): 3 min at 10°C
Heating Power/Consumption:
+ for Temp.: 3.0 kW
+ for Humi.: 3.0 kW
Compressor: 1 HP
Program Function: Temperature and Humidity: 120 Patterns, 1200 Segments, Light Bank: 7 steps
Door:
+ Internal: Tempered Safety Glass with Silicon Packing
+ External: 3-Side Magnetic Packing Door with Light Bank
Shelf(Included): 8 PE-coated Steel Shelf
Permitted Total Load: 128 kg (16kg x 8 Shelves)
Material: Internal: Stainless-steel(#304), External: Powder Coated steel
Dimension (w x d x h):
+ Interior (mm): 1200 x 790 x 1050
+ Exterior (mm): 1400 x 1150 x 1965
Packing size & Gross Weight: 1600 x 1500 x h2200mm, 585kg
Power Consumption: 6.5 kW
Power Supply: AC 230V , 50/60 Hz
Spare Wire Shelf, PE Coated steel:
DH.WGC10450: Wire Shelf, PE Coated, w640 x d620mm, "GCS450", for 432 Lit
DH.WGC11000: Wire Shelf, PE Coated, w580 x d620mm, "GCS1000", for 864 Lit
