DV Power RMO60E 保护接地电阻表

Mains power supply

• Connection according to IEC/EN60320-1; C320

• Mains supply: 90 V – 264 V AC

• Frequency: 50 / 60 Hz

• 12 A / 250 V, type F

Output data

• Test current range: 5 mA – 60 A DC

• Full load voltage: up to 12 V DC

• Open circuit voltage: 25 V DC

Measurement

• Resistance range 0.1 µΩ – 25.00 Ω

• Resolution:

0.1 µΩ – 999.9 µΩ,0.1 µΩ

1.000 mΩ – 9.999 mΩ, 1.0 µΩ

10.00 mΩ – 99.99 mΩ, 10 µΩ

100.0 mΩ – 999.9 mΩ, 0.1 mΩ

1.000 Ω – 9.999 Ω, 1 mΩ

10.00 Ω – 25.00 Ω, 10 mΩ

Display: LCD screen 20 characters by 4 lines; backlight, visible in bright sunlight.

Test Result Storage: RMO-E can store up to 500 measurements

Environmental conditions

• Operating temperature: -20 ºC - +55 ºC / -4 ºF - +131 ºF

• Storage & transportation: -40 ºC - +70 ºC / -40 ºF - +158 ºF

• Humidity: up to 95 % relative humidity

Dimensions and weight

• Dimensions (W x H x D): 198 mm x 255 mm x 380 mm/ 7.8 in x 10 in x 15 in

• Weight: 8 kg / 17.6 lbs
