DYS DWA - 3000B pH 分析和控制器 - 2点SET
制造商: DYS Model: DWA-3000B - 联系
Function / Features
- Certificate : New Excellent Product (NeP)
- Certificate : Certificate of Patent
- Certificate : Certificate of CE
- English Display.
- Real Time Trend Graph Function .
- Relay Contact output -High, Low Alarm & Cleaning Contact .
- Simple Operation by 7 Keypad Button.
- Large Size LCD Screen (160*128).
- Back-Light LCD.
- Isolated(4~20, 0~20, 0~24 mA DC) Output Transmission.
- RS-232 Communication.
- Automatic Cleaning Control(Air jet, Water jet) Function.
- Panel mounting (DIN144 size)
- Microprocessor-based Digital Program Controller
Specifications - Code No. : 413130002pH
- Model : DWA-3000B-pH
- Channel : Single channel
- Range : 0 ~ 14 pH (Resolution: 0.01)
- Meas. Method : Combination glass electrode
- Power : AC 110/220V, 50/60Hz, 3VA
- Accuracy : ±0.1 pH of F.S
- Repetition & Reappearance : ±0.1 pH of F.S
- Response time : 60 sec(90% saturation)
- Analog output : 4~20mA DC(STD.)
- Digital output : RS-232C
- Relay output : High, Low & Cleaning Contact
- Display : Trend graph, measuring value, Temp
- Humidity : max. 90%(non-condensing)
- IP Rating : IP65
- Size : 155(W)x155(H)x184(D)
- Installation : Panel mounting (DIN144 size)
OPTION:
|
PH ELECTRODE |
|
PRICES (USD) |
|
+ PH Electrode ONLINE FOR WATER AND WATER PURITY, BODY BY PPS Model PP34 Manufacturer: DYS – Korea PH electrode using appropriate online measurements in water and purified water. |
1 |
210 |
|
+ PH Electrode ONLINE FOR WATER TREATMENT, BODY BY PPS |
1 |
240 |
|
+ PH Electrode ONLINE FOR WATER AND PURE WATER, WITH GLASS BODY |
1 |
240 |
|
+ PH Electrode ONLINE FOR WATER TREATMENT, BODY WITH GLASS |
1 |
240 |
|
+ PH Electrode ONLINE FOR PROCESSING INDUSTRY |
1 |
165 |
