DYS DWA - 3000B pH 分析和控制器 - 2点SET

Function / Features

- Certificate : New Excellent Product (NeP)
- Certificate : Certificate of Patent
- Certificate : Certificate of CE
- English Display.
- Real Time Trend Graph Function .
- Relay Contact output -High, Low Alarm & Cleaning Contact .
- Simple Operation by 7 Keypad Button.
- Large Size LCD Screen (160*128).
- Back-Light LCD.
- Isolated(4~20, 0~20, 0~24 mA DC) Output Transmission.
- RS-232 Communication.
- Automatic Cleaning Control(Air jet, Water jet) Function.
- Panel mounting (DIN144 size)
- Microprocessor-based Digital Program Controller

 Specifications   - Code No. : 413130002pH
- Model : DWA-3000B-pH
- Channel : Single channel
- Range : 0 ~ 14 pH (Resolution: 0.01)
- Meas. Method : Combination glass electrode
- Power : AC 110/220V, 50/60Hz, 3VA
- Accuracy : ±0.1 pH of F.S
- Repetition & Reappearance : ±0.1 pH of F.S
- Response time : 60 sec(90% saturation)
- Analog output : 4~20mA DC(STD.)
- Digital output : RS-232C
- Relay output : High, Low & Cleaning Contact
- Display : Trend graph, measuring value, Temp
- Humidity : max. 90%(non-condensing)
- IP Rating : IP65
- Size : 155(W)x155(H)x184(D)
- Installation : Panel mounting (DIN144 size)



Detail

OPTION:

PH ELECTRODE



PRICES (USD)

+ PH Electrode ONLINE FOR WATER AND WATER PURITY, BODY BY PPS

Model PP34

Manufacturer: DYS – Korea

PH electrode using appropriate online measurements in water and purified water.
- Measuring range: 2-12 pH
- Temperature scale: 0 - 800C
- Temperature Sensor: Pt1000 sensor
- Maximum pressure: 0.6 Mpa
- Body electrode with PPS, 5m long cable
- Ren screw ¾ "NPT

1

210

+ PH Electrode ONLINE FOR WATER TREATMENT, BODY BY PPS
Model PW34
Manufacturer: DYS - Korea
- PH electrode suitable online measurement used in the wastewater.
- Measuring range: 0-14 pH
- Temperature scale: 0 - 1100C
- Temperature Sensor: Pt1000 sensor
- Maximum pressure: 0.6 Mpa
- Body electrode with PPS, 5m long cable
- Ren screw ¾ "NPT

1

240

+ PH Electrode ONLINE FOR WATER AND PURE WATER, WITH GLASS BODY
Model PP13F
Manufacturer: DYS - Korea
- PH electrode using appropriate online measurements in water and purified water.
- Measuring range: 0-14 pH
- Temperature scale: 0 - 800C
- Temperature Sensor: Pt1000 sensor
- Maximum pressure: 0.6 Mpa
- Body made ​​of glass electrodes, cable length 5m
- Ren screw ¾ "PG13.5

1

240

+ PH Electrode ONLINE FOR WATER TREATMENT, BODY WITH GLASS
Model PW31F
Manufacturer: DYS - Korea
- PH electrode suitable online measurement used in the wastewater.
- Measuring range: 0-14 pH
- Temperature scale: 0 - 1100C
- Temperature Sensor: Pt1000 sensor
- Maximum pressure: 0.6 Mpa
- Body made ​​of glass electrodes, cable length 5m
- Ren turned PG13.5

1

240

+ PH Electrode ONLINE FOR PROCESSING INDUSTRY
Model PW31F
Manufacturer: DYS - Korea
- PH electrode suitable online measurement used in the wastewater.
- Measuring range: 0-14 pH
- Temperature scale: 0 - 800C
- Maximum pressure: 0.3 Mpa
- Body made ​​of glass electrodes, cable length 5m
- Ren turned PG13.5

1

165
