E-survey eME10 GNSS 智能挖掘机导航系统

Resolution: 1280 x 800

OS: Android 7.0 9.0 (optional)

RAM: 2 GB DRAM

ROM: 16 GB EMMC

SD: Micro SD card

Channels: 1100

Frequency: 20 Hz

Input voltage: 7-36 V dc

Dimension: 170 mm x 70 mm x 40 mm

Positioning accuracy:

RTK: H: 8 mm + 1 ppm; V: 20 mm + 2 ppm

DGNSS: H: 0.3 m; V: 0.6 m

Single: H: 1.2 m; V: 2.5 m

SBAS: H: 0.3 m; V: 0.6 m

Heading accuracy:

< 0.09° rms @ 1.0 m

< 0.04° rms @ 2.0 m

< 0.02° rms @ 5.0 m

< 0.01° rms @ 10 m
