EA Elektro-Automatik PS 5200-04 A 可编程台式直流电源 (200V; 4A; 320W)

Input voltage AC : 90...264 V

- Frequency : 45...65 Hz

- Power factor : >0.97

Output voltage DC : 0...200 V

- Load regulation 0-100% load : <0.08%

- Line regulation ±10% ΔUAC : <0.02%

- Ripple (1 ): <150 mVPP <30 mV RMS

- Regulation 10-100% load : <1.5 ms

- Accuracy (2 ): ≤0.2%

Output current : 0...4 A

- Load regulation 0-100% ΔUDC : <0.15%

- Line regulation ±10% ΔUAC : <0.02%

- Ripple (1 ): <16 mAPP

- Accuracy (2 ): ≤0.2%

Output power : 0...320 W

- Accuracy (2 ): ≤1%

Cooling : Fan

Operation temperature : 0...50 °C

Storage temperature : -20...70 °C

Dimensions (3) (WxHxD) : 200x87x301 mm

Weight : 3 kg

(1 ) RMS value: measured at LF with BWL 300 kHz, PP value: measured at HF with BWL 20MHz

(2)At 23 °C ±5 °C

(3) Enclosure only, not over all
