EA Elektro-Automatik PSB 10920-125 可编程双向直流电源 (920V; 125A; 30000W)

DC output:

Voltage range : 0 - 920 V

Ripple in CV (rms) : ≤250 mV (BW 300 kHz)

Ripple in CV (pp) : ≤1200 mV (BW 20 MHz)

U Min for IMax (sink) : 2 V

Current range : 0 - 125 A

Power range : 0 - 30000 W

Resistance range : 0.25 Ω - 550 Ω

Output capacitance : 100 μF

Effi ciency sink/source (up to) : 96.5% *1

Insulation:

Negative DC pole <-> PE : ±1500 V DC

Positive DC pole <-> PE : +2000 V DC

*1 At 100% power and 100% output voltage
