Dimension: 228mm×98mm×60mm(Holding part 70mm width×36mm thick (Do not include plug and leading cable).
Power supply:three AA alkaline or rechargeable Ni-MH batteries.
Support the following Instruments:
Yokokawa EJA, EJAX;
SIMENS PDS, DSIII, PS2 valve position, P300, LR200 radar level meter;
ABB 2600 series;
a) HART connection meets HCF criteria.
b) ±28V common-mode voltage can be accepted by HART® connection.
c) Typical value of leakage current is less than 1.0uA@25℃
d) Communication distance of HART connection is 1500m
e) HART communication connection has anti-EMI measures.
f) HART communication connection has automatic amplitude multiplier function.
LCD screen is 8 line×21bite display
It is normal that LCD display responds slowly when ambient temperature is too low. Because of automatic temperature compensation circuit of device, LCD display still has a very good contrast to facilitate your use in different environment
