EBP B-62.5DT低负荷数字布氏硬度计

Test Force (Kg): 1, 2.5, 5, 6.25, 10, 15.625, 25, 30, 31.25, 62.5 Total 10 types

Ball Diameter (mm): 5mm,2.5mm,1mm

Test force: Automatic unloading test force

Test force dwell time: 0 ~ 60S (one unit per second)

Objective magnification: 5X, 10X

Illumination: Exterior lighting, each lens comes with a light source

Eyepiece magnification: 10 × (automatic digital encoder)

Minimum test unit: 0.25μm

Data correction: Each lens, automatic correction respectively

Hardness test range: 4-650HBW

Test space: 180*160mm (H*D)

Data output: U disk

Power supply: AC220V+5%,50-60Hz

Dimensions: 720*190*650mm

Weight: 40Kg Standard


Accessories:

Digital measuring eyepiece 1

Brinell Hardness block 2pcs

Power cord 1

Large, medium, V-type testing bench 1 Each

USB flash disk 1

Fuses 2pcs

Manufacturer certificate 1

Operation Instruction 1
