EEC EST-320 耐压测试仪

INPUT RATING

• Voltage (AC): 100 - 120Vac / 200 - 240Vac±10% Auto Range

• Apparent Power: 360 VA

• Frequency: 50/60 Hz ± 5%

AC WITHSTAND VOLTAGE

• Output Rating: 5KVAC / 20mA

• Output Voltage Range: 0 - 5.00 kVac

• Voltage Resolution: 0.01 kVac

• Voltage Accuracy: (1% of setting + 0.5% of Range)

• Current Measurement Range: 0.000 - 20.00 mA

• Current Resolution: 0.001 / 0.01 mA

• Current Accuracy: (1% of reading + 1% of Range)

INSULATION RESISTANCE

• Output Rating: 1KVDC / 50 Gї

• Output Voltage Range: 30 - 1 KVdc

• Voltage Resolution: 1 Vdc

• Voltage Accuracy: (1% of setting + 0.5% of Range)

• Resistance Measurement Range: 0.100 Mї - 50 Gї

• Resistance Resolution: 0.001 / 0.01 / 0.1 /1 Mї

• Resistance Accuracy:

0.100 - 999.9 MΩ under 30-499V: ±(7% of reading+0.1% of Range)

1 - 10 GΩ under 30-499V: ±(15% of reading+0.1% of Range)

0.500 - 999.9 MΩ under 500-1000V: ±(2% of reading+0.1% of Range)

1 - 9.999 GΩ under 500-1000V: ±(5% of reading+0.1% of Range)

10 - 50 GΩ under 500-1000V: ±(15% of reading+0.1% of Range)

GENERAL

• Interface: USB, PLC Remote

• Display: 4.3" Color Display (Touch Panel)

• Environment: 0 - 40°C, 20 - 80%RH

• Dimension (W x H x D), mm: 215 x 88.1 x 300

• Net Weight: 5.46 Kg
