Elma P 300 H 超声波清洗器

Mains voltage (Vac) 115-120 V/220-240 V

Ultrasonic frequency (kHz) 37 / 80

Power consumption total P 300 H (W) 1630

Ultrasonic power effective (W) 380

Ultrasonic peak performance max.(W) 1520

Heating power (W) 1250

Unit outer dimensions W/D/H (mm) 568 / 340 / 321

Tank internal dimensions W/D/H (mm) 505 / 300 / 200

Basket internal dimensions W/D/H (mm) 455 / 250 / 115

Max. filling volume tank (lit.) 28.0

Elma Order Nos.

Elmasonic P 300 H (220-240 V) 101 3810

Elmasonic P 300 H (115-120 V) 103 8008

Basket stainless steel 100 4271

Cover (plastic) 1003287

Further accessories on request

Weight (kg) 11.0

Material tank stainless steel V2A

Material casing stainless steel V2A

Drain 3/8“

CE-compliant √

Protection class IP 20

Sound pressure level (LpAU) * (dB) <70

Ultrasonic sound level (LpZ) ** (dB) <105
