ESPEC EHS-431 Large Highly Accelerated Stress Test System (105~162.2°C, 75~100%rh, 130L)

Dimensions:

      Test chamber internal dimensions: φ635×L728 mm (130 L)

      External dimensions (W×H×D): W800×H1575×D1260

Performance:

      Unsaturated control:

             Temperature control range: 105.0 - 162.2°C

             Humidity control range: 75 - 100% rh

             Pressure range: 0.0196 - 0.392 MPaG

     Wet-saturated control:

             Temperature control range: 105.0 - 151.1°C

             Pressure range: 0.0196 - 0.392 MPaG
